SCOM MS TLS1.2 drivers

SCOM MS TLS1.2 drivers
SCOM MS TLS1.2 drivers

Courtesy of Brook Hudson, who provided clarification for encrypting SCOM data –

Question – Can we update the OLE DB Driver from 18.6.5 to 18.6.7 and the ODBC driver from 17.10.3 to 17.10.5.1 without breaking anything?



This configuration applies to SCOM2016 forward –

MS OLE DB Driver 18.6.7: https://go.microsoft.com/fwlink/?linkid=2242656

ODBC Driver 17.10.5.1: https://go.microsoft.com/fwlink/?linkid=2249004





I did NOT have success with this for SCOM2019 and SCOM2022 –

If the SQL endpoint is secured with encryption, then the following drivers can be used.

MS OLE DB Driver 19.3.2: https://aka.ms/downloadmsoledbsql

ODBC Driver 18.3.2.1: https://aka.ms/downloadmsodbcsql

If you want to use these newer drivers then SQL encryption is required, more information about enabling SQL Encryption: Configure SQL Server Database Engine for encryption – SQL Server | Microsoft Learnhttps://learn.microsoft.com/en-us/sql/database-engine/configure-windows/configure-sql-server-encryption?view=sql-server-ver15



The SQL team noted that the newer versions are defaulting Encrypt to be Yes/Mandatory. That is why the new drivers were having an issue. Setting up a certificate in the SQL endpoint would have allowed the connection to work:

Enable encrypted connections – SQL Server | Microsoft Docs

Certificate Management (SQL Server Configuration Manager) – SQL Server | Microsoft Docs

OLE DB Driver 19.0 for SQL Server Released – Microsoft Tech Community

ODBC Driver 18.0 for SQL Server Released – Microsoft Tech Community



IMPORTANT:

Update: Hotfixes released for ODBC and OLE DB drivers for SQL Server – Microsoft Community Hub



ServiceNow Event integration

ServiceNow Event integration
ServiceNow Event integration
Time to integrate your Monitoring tools to ITSM tool.  First, this blog post documents ‘ServiceNow Event integration’.  Second, let’s explain the common acronym in my experience is SNOW/SNow.  Third, some background – ServiceNow has been around for some time as an Information Technology Service Management (ITSM), and discovery tool.  As a SaaS solution, companies can purchase a subscription and integrate tools via RESTAPI to create/update/close events or incidents.
First, let’s begin to discuss SCOM notification methods.  SCOM2022 adds a new capability with Teams integration.  Second, most people are familiar with notification methods leveraging Email (html or not), perhaps SMS, but not so much command channel, calling some script in shell, PowerShell, etc.  Generally, the command channel is basically a post processing script capability to execute notifications.  Third, example tools where command channel might be used – BMC BEM (BMC Event Manager), BMC Remedy, xMatters, DerDack; SNOW integration within SCOM, using notification channels.  Lastly, SaaS solutions (vendors like xMatters, and ServiceNow) allow RESTAPI crafted requests to take actions.
SNOW prerequisites
1) ServiceNow User/Password (or API key)
2) SNOW RESTAPI PowerShell needs to securely access credentials
For the Incident PowerShell, we store Credentials within Windows Credential Manager
3) Network connectivity to SaaS provider (use PowerShell test-netconnection from SCOM MS to test connectivity over whatever port(s) vendor requires.
4) ServiceNow CallerID GUID
5) Production and Test URL’s (also required for network connectivity tests)
6) Access to SNOW UI to verify required fields and values for the script parameters.
Update incident script and begin testing.
Download script from GitHub repo https://github.com/theKevinJustin/New-SNowEvent/
Download script, and copy to monitoring repository
Copy to SCOM management servers (MS)
NOTE Path, to run from management server
Update script, with pre-reqs above –
Credential Manager stored ID
For more detail, look at parameter examples below to verify UI.
Update with customer/ServiceNow SNOW subscription specific values:
##CallerID##
##CUSTOMER##    (customize SNOW short_description)
##TEAM##    (customize SNOW short_description)$Channel = “Direct”
$ServiceNowURL=”https://##SERVICENOWURL##/api/now/table/em_event”
$CallerID = “##CallerID##”
# if proxy is used, uncomment and replace with Proxy URL
#$Proxy = “##Proxy##”
# Test New-SNOWEvent.ps1
# Depending on how you want to randomly choose an alert to create SNOW event
Lab example
$Alerts = get-scomalert -resolutionstate 0 | where { $_.Name -like “System Center*” }
Gather Critical, New alerts
$Alerts = get-scomalert -ResolutionState 0 -severity 2
Debug for warning alerts
$Alerts = get-scomalert -ResolutionState 0 -severity 1
# Debug
$Alerts[0] | fl ID,Name,Description,Severity,MonitoringObjectDisplayName
.\New-SNOWEvent.ps1 -AlertName $Alerts[0].Name -AlertID $Alerts[0].ID -Impact 4 -Urgency 4 -Priority 3 -AssignmentGroup “System Admin” -BusinessService “System Management” -Category Support -SubCategory Repair -Channel Direct
Example output
PS C:\Users\scomadmin\Desktop> .\New-SNOWIncident.ps1 -AlertName $Alert.Name -AlertID $Alert.ID -Impact 4 -Urgency 4 -Priority 3 -AssignmentGroup “System Admin” -BusinessService “System Management” -Category Support -SubCategory Repair -Channel Direct
TEST ServiceNow URL specified.
CredentialManager PoSH Module Installed, ModuleBase = C:\Program Files\WindowsPowerShell\Modules\CredentialManager\2.0
The System Center Management Health Service 5E04F804-8B71-6EB6-0101-DCBB58022498 running on host 16DB02.testlab.net and s
erving management group with id {E39F5F53-9FBB-9D7F-4BFE-5F0324630AE5} is not healthy. Some system rules failed to load.
16DB02
Warning
impact 4
urgency 4
priority 3
ServiceNow Credential NOT stored on server

SCOM maintenance schedules

SCOM maintenance schedules
SCOM maintenance schedules
Do your SCOM users need to know if a server is in scheduled maintenance?  This came about as Aris asked questions.
 First, let’s discuss specific maintenance mode and maintenance schedule scenarios users might ask.  Second, determining IF scheduled maintenance enabled, running, about to run.  Third, how does another user know when scheduled maintenance ends, allowing action and decision point to add/extend server maintenance.  Fourth, whenever scheduled maintenance entered by one user, is NOT automatically seen by other roles.  While product guidance states ‘maintenance schedules be added by someone in SCOM admin group’, self-service users still need visibility.  Lastly, can we figure out a way to answer these questions.  Given these points, users to be able to see server maintenance details.  Also, can solution adhere to best practice ‘no alerts during planned maintenance’.
From PowerShell on SCOM MS
Get-SCOMMaintenanceScheduleList
$ScheduleList = Get-SCOMMaintenanceScheduleList
$ScheduleList.ID
$ScheduleList.ScheduleID.Guid
foreach ( $ID in $ScheduleList.ScheduleID)
{
$Schedule = get-SCOMMaintenanceSchedule -ID $ID
# $Schedule.MonitoringObjects ;
(get-scomclassInstance -id $Schedule.MonitoringObjects.Guid).DisplayName
# Debug endtime
$Schedule | ft User,ActiveStartTime,ActiveEndDate,ScheduledEndTime
}
Example Output
SCOM Maintenance Schedule Output
SCOM Maintenance Schedule Output
Workflows:
Scheduled Maintenance report task
Maintenance mode report – what’s about to end maintenance mode.
Obviously, expect both workflows into the ‘Proactive NOSC DailyTasks’ pack.  GitHub repo  https://github.com/theKevinJustin/ProactiveNOSCDailyTasks

SQL SysMessages 18054 events



SCOM2016+ SQL SysMessages 18054 events
SCOM2016+ SQL SysMessages 18054 events

Whether you’re building a new SCOM2019, SCOM2022 environment or not, you might be missing these event details, and NOT even know!



It’s been a while for me, and I came across these, so posting for a fresh heads up!

Leverage Holman’s TXT files to keep your logging up to maximum potential!  Use the information below to resolve SCOM2016+ SQL SysMessages and 18054 events.

Holman GitHub download – contains SQL TXT files to run on OpsMgr & DW databases https://github.com/thekevinholman/SQLFix18054EventsSysmessages



The Github TXT files to download contain a clear scope of messages.



SQL messages excerpt

—————————————–
— MOMv3 messages are 77798xxxx —
—————————————–

———————————————–
— Discovery range: 77798-0000 to 77798-0049 —
———————————————–
— Managed type doesn’t exist.
EXECUTE sp_addmessage @msgnum = 777980000, @msgtext = N’The specified managed type doesn”t exist.’, @severity = 16, @lang = ‘us_english’, @with_log = false, @replace = ‘REPLACE’
GO

— Relationship type doesn’t exist.
EXECUTE sp_addmessage @msgnum = 777980001, @msgtext = N’The specified relationship type doesn”t exist.’, @severity = 16, @lang = ‘us_english’, @with_log = false, @replace = ‘REPLACE’
GO

— Source entity of the relationship doesn’t exist.
EXECUTE sp_addmessage @msgnum = 777980002, @msgtext = N’The specified relationship doesn”t have a valid source.’, @severity = 16, @lang = ‘us_english’, @with_log = false, @replace = ‘REPLACE’
GO

— Target entity of the relationship doesn’t exist.
EXECUTE sp_addmessage @msgnum = 777980003, @msgtext = N’The specified relationship doesn”t have a valid target.’, @severity = 16, @lang = ‘us_english’, @with_log = false, @replace = ‘REPLACE’
GO

— Discovery data from invalid managed entity is dropped.
EXECUTE sp_addmessage @msgnum = 777980004, @msgtext = N’Discovery data has been received from a rule targeted to a non-existent entity. The discovery data will be dropped.’, @severity = 16, @lang = ‘us_english’, @with_log = false, @replace = ‘REPLACE’
GO

— Invalid relationship rejected by cycle detection.
EXECUTE sp_addmessage @msgnum = 777980005, @msgtext = N’Relationship {%s} was rejected because it would cause a containment cycle; relationship source = ”%s” and target = ”%s”.’, @severity = 16, @lang = ‘us_english’, @with_log = false, @replace = ‘REPLACE’
GO

— Discovery data generated by invalid connector.
EXECUTE sp_addmessage @msgnum = 777980006, @msgtext = N’Discovery data generated by invalid connector:%s.’, @severity = 16, @lang = ‘us_english’, @with_log = false, @replace = ‘REPLACE’
GO

— Discovery data generated by invalid rule, task, discovery.
EXECUTE sp_addmessage @msgnum = 777980007, @msgtext = N’Discovery data generated by invalid discovery source. Id:%s.’, @severity = 16, @lang = ‘us_english’, @with_log = false, @replace = ‘REPLACE’
GO

Documentation links

Blog for 18054 events https://kevinholman.com/2017/08/27/scom-2016-event-18054-errors-in-the-sql-application-log/

SCOM 2016, 2019 and 2022: Event 18054 errors in the SQL application log

Alternatively, if AlwaysOn configuration, leverage Holman’s newer blog post – https://kevinholman.com/2022/10/02/scom-deployment-configuration-for-sql-always-on/

SCOM deployment configuration for SQL Always On



SQL STIG vulnerabilities V-213902, V-213935

Happy leap year, let’s talk Security and SQL STIG vulnerabilities V-213902, V-213935!
Happy Leap year
Happy Leap year

DISA DOD SQL STIG vulnerabilities V-213902, V-213935

SQL DBA team for RCC-C customer requesting documentation for exception, in light of vulnerabilities.
V-213902
V-213935
SCOM uses individual computer accounts in SQL for these findings
Holman documented this since 2012

SCOM SECURITY Documentation

SCOM2019 https://kevinholman.com/2020/07/23/scom-2019-security-account-matrix/

Both V-213902 AND V-213935 state same identification action.

Run this SQL Query on SCOM DB(s)
SELECT name
FROM sys.database_principals
WHERE type in (‘U’,’G’)
AND name LIKE ‘%$’
To remove users:
Run the following command for each user:
DROP USER [ IF EXISTS ] ;

V-213935 has a different identifier:

Launch PowerShell.
Execute the following code:
Note: <name> represents the username portion of the user. For example; if the user is “CONTOSO\user1$”, the username is “user1”.
([ADSISearcher]”(&(ObjectCategory=Computer)(Name=<name>))”).FindAll()
If no account information is returned, this is not a finding.
If account information is returned, this is a finding.

Tab delimited view –

Remove Computer Accounts DB SQL6-D0-000400 V-213902 CAT II Non-repudiation of actions taken is required in order to maintain data integrity. Examples of particular actions taken by individuals include creating information, sending a message, approving information (e.g., indicating concurrence or signing a contract), and receiving a message.
Remove Computer AccountsSQL6-D0-004200V-213935CAT IINon-repudiation of actions taken is required in order to maintain data integrity. Examples of particular actions taken by individuals include creating information, sending a message, approving information (e.g., indicating concurrence or signing a contract), and receiving a message.
Can provide one work-around to mitigate.
Awaiting CSS engagement for official mitigation from support and  SCOM PG.

January addendum updates

Fast and Furious (sarcasm and humor)
Fast and Furious (sarcasm and humor)

January addendum updates for multiple management packs

First, the biggest change item for large enterprise environments included a change in syntax for get-SCOMAlert
Example
get-scomalert -ResolutionState (0..254) -Name “##stringhere##*”
get-scomalert -ResolutionState 255 -Name “##stringhere##*”
Second, another change with the repo’s was a ‘whitespace audit’ encoded characters, or ‘data concealment’.  See AT&T link CyberSecurity Link
Third, after whitespace we focused on script/workflow efficiencies seen in large enterprise environments.  While Efforts began in December, the workflow efficiencies sprint resulted in two sets of improvements.
Fast and Efficient
Fast and Efficient
1) Added ‘Reset Monitors Script base code’ $Age variable
What does this mean?
Simply put $Age allows admins to define monitor age before resetting.
The default is 1 (day), but can be specified in the script to tailor to requirements.
Example
$Age = [DateTime](Get-Date).AddDays(-1)
2) Beyond incorporating $Age into the reset monitor logic, the packs utilize logic for a much faster runtime (~90%+).
What does this mean?
Updated logic quickly gathers unhealthy monitor objects, by leveraging ‘Get-SCOMManagementPack‘ and then ‘Get-SCOMClass‘, before passing to ‘Get-SCOMClassInstance‘.
Example PowerShell
## Grab the MP, get the Monitors and Rules from the MP, then grab all alerts found inside the Monitors/Rules
$SCOMCoreMP = Get-SCOMManagementPack -DisplayName “Microsoft Windows Server DNS Monitoring”
# Get classes – Examples –
$Monitoring = $SCOMCoreMP
# DNS pack naming
$DNSClasses = @(Get-SCOMClass -ManagementPack $Monitoring; )
$DNSClass = $DNSClasses | sort -property Name -uniq

Repo’s updated in January

January addendum updates include:
ADCS, ADDS, DNS, DFS/File Services, IIS, SCCM pack for MECM/MEM/MCM monitoring, Operating Systems, Proactive NOSC Daily Tasks, and Tangible ProV application monitoring.

Links below to GitHub repositories (repo’s)

Improving SCOM Monitor reset logic

Faster - Improving SCOM Monitor reset logic
Faster – Improving SCOM Monitor reset logic



My thanks to Aris Somatis for his deep dive reviewing the packs with me, particularly new use cases.  The PowerShell below builds on Scott Murr’s initial TechNet published logic from years back.  Consequently, the reset logic provides a ‘manual intervention required’ alerting/monitoring system.





Improving SCOM monitor reset logic

Calling the reset method has been a game changer for my customers – including operators, system and application owners!

Background

Scott’s reset logic, from SCOM2012, helped administrators reset unhealthy monitors where alerts may have been closed.  Because Scott leveraged the ResetMonitoringState method, the community gained a way to keep true health.  Additionally, many administrators and engineers built custom management packs to provide solutions.  Second, the addendum packs blog brought in more options – best practices, lessons from the field (and customers), and health model accurate alerting for what was really broken in the environment.  Third,    addressing ‘gaps’ or ‘blind spots’ from product teams.   As a result of NEW monitoring, the packs may include: rules/monitors, datasource/writeAction (DS/WA) workflows, recovery tasks and automation, count logic monitors, overrides, discoveries, and groups.    Thirdly, to take monitoring to the next level.  To top that off, with very little/NO cost compared to competitors!

PowerShell code

Aris’s Age use case takes this even further.  Using monitor age allows further analysis to dial down ‘monitor reset’ to object is X days old.  Comparatively, the 24-72 hour setup default is used in the addendums, so Age provides a second option.  Third option can rely on SCOM’s built-in cleanup, but that’s typically 14-30 days.   Overall, flexibility is a good thing.



# Specify age variable for your environment

$Age = [DateTime](Get-Date).AddDays(-7)



PowerShell code snippet

First, the reset logic can pivot on the age requirement.  Then, adjust the Age variable per requirements.  Third, figure out which method applies to gather a unique list of classes, whether by partial string(s), or by management pack name(s).



Set age variable (how long ‘OLD’ monitors might be stale and need reset)

# Example sets $Age variable to 7 days ago (-7)

$Age = [DateTime](Get-Date).AddDays(-7)





Unpack two different ways to gather classes for monitors to reset

# When common string name exists in all classes

Example DFS/FileServices packs all have one of the three strings:

# DFS pack naming

$DFSClasses = @(Get-SCOMClass -Name “*FileServices*”; Get-SCOMClass -Name “*FileServer*”; Get-SCOMClass -Name “*DFS*” )

$DFSClass = $DFSClasses | sort -property Name -uniq

# Debug

$DFSClass.Count



# Get AD classes – Microsoft.Windows.Server.AD.2016.Discovery, Microsoft.Windows.Server.AD.Library

$ADLibrary = Get-SCOMManagementPack -name “Microsoft.Windows.Server.AD.Class.Library”

#get-scomclass -ManagementPack $ADLibrary

$ADMonitoring = Get-SCOMManagementPack -name “Microsoft.Windows.Server.AD.2016.Monitoring”

#get-scomclass -ManagementPack $ADMonitoring | fl DisplayName,Name,ID

$ADDiscovery = Get-SCOMManagementPack -name Microsoft.Windows.Server.AD.2016.Discovery

#get-scomclass -ManagementPack $ADDiscovery | fl DisplayName,Name,ID

# ADDS pack naming

$ADDSClasses = @(Get-SCOMClass -ManagementPack $ADLibrary; Get-SCOMClass -ManagementPack $ADDiscovery; )

# NOTE Excluded AD Monitoring pack as NO classes existed

$ADDSClass = $ADDSClasses | sort -property Name -uniq



# Debug count of unique classes

$ADDSClass.Count





Reset monitor PowerShell screenshot

Download from GitHub https://github.com/theKevinJustin/SCOMMonitorReset

SCOM Reset PowerShell
SCOM Reset PowerShell



Example PowerShell on HealthService resets

NOTE debug logic enabled

0
Found 0 unhealthy monitors for class Microsoft.SystemCenter.HealthServicesGroup
1
Found 1 unhealthy monitors for class Microsoft.SystemCenter.HealthServiceWatcher

Resetting Health State on ' + Microsoft.SystemCenter.HealthServiceWatcher:Microsoft.SystemCenter.AgentWatchersGroup;5e0
4f804-8b71-6eb6-0101-dcbb58022498 + '

Guid
----
0218d239-3d37-f9b1-75d2-6d52c2c7c0c1


Documentation/Sources

Building on Scott’s idea – (retired links)
Original post https://sc.scomurr.com/scom-2012-monitor-reset-cleaning-up-the-environment/
TechNet gallery download https://gallery.technet.microsoft.com/SCOM-2012-Batch-reset-63a17534
Alternate link https://gallery.technet.microsoft.com/scriptcenter/Auto-reset-script-for-d8b775ca

PowerPoint soft skills

PowerPoint soft skills headshot
PowerPoint soft skills headshot

Do you have expert PowerPoint soft skills?  Are you an expert presenter?  I’ll bet there’s at least one item here you might not know.  Fortunate to have spent some time learning from Asia Platt, Brittany Holloway, and Mauricio Fuentes about expert presentations.  Let’s go over some tips and tools to improve what you present, for more interaction, clarity, and more.



Quick Overview

Magnification tools like Magnifier, ZoomIt, and Teams

Laser pointer in PowerPoint

Rehearse and record PPT slide deck

Soft Skills tips and tricks





Magnification tools

Zoom – Can you see this?

Various methods for Zooming (including Teams)

Zoom - Can you see this?
Zoom – Can you see this?



Do you struggle with demo’s to present screens that customers struggle to view?  See some magnifier tool options from windows client/server, teams, and PowerPoint below.

Magnifier (on Windows client/servers)

Click on Start > type Magnifier

Windows Magnifier to zoom in on live demo's.



Change zoom level

Move mouse to focal point

Move to focal for zoom.
Move to focal for zoom.



BE careful and don’t move mouse too much!!





ZoomIt

Good utility for demo’s and presentations.  Zoom, draw, whiteboard, type pen (in colors), and more

ZoomIt SysInternals free tool download https://learn.microsoft.com/en-us/sysinternals/downloads/zoomit

Shortcuts link

ZoomIt SysInternals Shortcuts.
ZoomIt SysInternals Shortcuts.

Teams built in Zoom

My own personal preference is Teams.  Demo’s can work in a pinch if only Magnifier is involved in a lab demo.

Zoom in/out of Teams shared application/screen https://support.microsoft.com/en-us/office/zoom-in-and-out-in-microsoft-teams-dc3cd3d8-efb5-4995-8b31-434b3943ba52

Use Teams features to zoom in and out, and more in meetings, calls, and screen shares.
Use Teams features to zoom in and out, and more in meetings, calls, and screen shares.





Laser pointer in PowerPoint

Hit the Control Key to turn your mouse into a pointer, allowing your audience to know ‘what’ is being emphasized.

Click Control, or Control-L for Laser pointer when presenting in PowerPoint.

Click Control, or Control-L for Laser pointer when presenting in PowerPoint.
Click Control, or Control-L for Laser pointer when presenting in PowerPoint.





Rehearse with coach

Record PPT slide deck

Asia (Asha) suggested this method to record delivery for analysis.  This helps check tone, pace, filler words, and more.



From PowerPoint, click on Slide Show > Rehearse with coach

PowerPoint Rehearse - record and get analysis from practicing your presentation.

PowerPoint Rehearse – record and get analysis from practicing your presentation.Go through presentation, and view analysis

PowerPoint rehearsal analytics showing pace, tone, and more.
PowerPoint rehearsal analytics showing pace, tone, and more.

Second page screenshot of more details

PowerPoint rehearsal analytics bottom half of screen.
PowerPoint rehearsal analytics bottom half of screen.





Soft Skills tips and tricks

  1. PowerPoints ‘Rehearse with Coach’ is an awesome way to practice and level set delivery.
  2. Magnification tools – Magnifier, ZoomIt, Teams (built in Zoom)
  3. Be creative and be yourself in delivery!
Be creative and be yourself in delivery.
Be creative and be yourself in delivery.

3. Involvement

Soft Skill Involvement
Soft Skill Involvement
Involvement example

Interaction soft skill – personalization.

I utilized this to reinforce (from my introduction), as an audience check in, gauging involvement.  This helped me gauge where the audience was attention wise.  Required audience thought before answering.

Interaction soft skill - personalization.  Where from my introduction, I used this to quiz the class to gauge interest and where the audience was attention wise.  Audience had to think about the slide to answer.
Interaction soft skill – personalization. Where from my introduction, I used this to quiz the class to gauge interest and where the audience was attention wise. Audience had to think about the slide to answer.







Hope this article provided another tool in the Presentation Soft Skills toolbox!

Hope this gave another tool in the Presentation Soft Skills toolbox!

Hope this gave another tool in the Presentation Soft Skills toolbox!

Delete PKI certificates

Don't you wish this were the certificates we worked with!
Don’t you wish this were the certificates we worked with!



Man, I wish I had a few of these certificates in my PKI infrastructure (portfolio)!  Ever need to identify an expired certificate, and or delete the certificate?  Depending on UAC, AppLocker, and other settings, the delete portion may require server logon.





Identify an expired certificate

Few ways to identify an expired certificate on servers.

Via RDP session to server

RDP to server, open MMC > Add Plug In > Certificates > for Computer

RDP to server, MMC, Certificates Plug In, Computer, expand certificate store to find expired certificate.
RDP to server, MMC, Certificates Plug In, Computer, expand certificate store to find expired certificate.



Via PowerShell

GCI Cert:\LocalMachine\*

The certificate store file path will vary the above command.

NOTE the SuperUser blog post will help decipher the folder name



Via ‘smart’ PowerShell across multiple machines

Courtesy of Vance Cozier!

“server1”,”server2″| % {invoke-command $_ -scriptblock {$env:ComputerName; GCI Cert:\LocalMachine\* }}



Via Monitoring for expired certificates

Using SCOM Certificate Monitoring or PKI monitoring management packs

Identify Expired certificates

Console navigation steps:

From SCOM console > Monitoring Tab

Expand PKI folder > Expand Certificates and CRLs folder

Click on ‘Certificates – Expired’ state view

SCOM Expired PKI certificates state view.
SCOM Expired PKI certificates state view.



Did you know

Run PowerShell commands from Holman’s SCOM Management pack (blog)- github download

Run PowerShell from Monitoring tool

From SCOM console > Monitoring Tab > SCOM Management folder > SCOM Agents

Highlight agent(s)

From Tasks Pane > click on ‘Execute any PowerShell’ task

SCOM Management pack, SCOM Agents, highlight agent(s), click on Task Pane > Execute any PowerShell task.
SCOM Management pack, SCOM Agents, highlight agent(s), click on Task Pane > Execute any PowerShell task.

On the pop-up window, click Override

Adjust timeout to 70 (seconds)

Override command line

Run the following commands (various Certificate store examples provided for removing expired certificates)

Personal Certificates folder

Get-ChildItem Cert:\LocalMachine\My | ? { (( $_.Subject -like “*GlobalSign*” ) -OR ( $_.Issuer -like “*GlobalSign*” )) -and $_.NotAfter -lt (get-date) } | fl Subject,Issuer

Trusted Root folder

Get-ChildItem Cert:\LocalMachine\Root | ? { ( $_.Subject -like “*GlobalSign*” ) -OR ( $_.Issuer -like “*GlobalSign*” ) } | fl  Subject,Issuer

Third Party Root

Get-ChildItem Cert:\LocalMachine\AuthRoot | ? { (( $_.Subject -like “*GlobalSign*” ) -OR ( $_.Issuer -like “*GlobalSign*” )) -and $_.NotAfter -lt (get-date) } | fl Subject,Issuer

Run PowerShell task.
Run PowerShell task.

Click OK button to close Overrides window

Click OK to run task

View task output

PS C:\Users\admin> Get-ChildItem Cert:\LocalMachine\Root | ? { ( $_.Subject -like “*GlobalSign*” ) -OR ( $_.Issuer

like “*GlobalSign*” ) } | fl Subject,Issuer



Subject : CN=GlobalSign Root CA, OU=Root CA, O=GlobalSign nv-sa, C=BE

Issuer  : CN=GlobalSign Root CA, OU=Root CA, O=GlobalSign nv-sa, C=BE

Subject : CN=GlobalSign, O=GlobalSign, OU=GlobalSign Root CA – R2

Issuer  : CN=GlobalSign, O=GlobalSign, OU=GlobalSign Root CA – R2





Once task completes, go back to the Certificates state view > highlight the certificate > Click the Rediscover Certificates task

SCOM PKI Certificate state view
SCOM PKI Certificate state view







Delete PKI certificates

After identifying correct certificate and folder in question that requires deletion:

    1. Verify backup of certificate
    2. Test delete via PowerShell window from SCOM

Get-ChildItem Cert:\LocalMachine\AuthRoot | ? { ( $_.Subject -like “*GlobalSign*” ) -OR ( $_.Isser -like “*GlobalSign*” ) } | Remove-Item -DeleteKey

  1. Verify Task output shows certificate deleted
  2. Refresh MMC GUI > Certificates plug in, and folder to verify certificate deleted
  3. Go back to SCOM Console Monitoring Tab
  4. Expand PKI folder
  5. Expand Certificates and CRLs folder
  6. Click on Certificates – Expired state view
  7. In Tasks pane on right, click on Rediscover certificates task, Click OK to run
  8. Open Health Explorer and reset monitor to clear alert

Alternatively, leverage PowerShell reset logic on SCOM MS, use blog





Documentation

SCOM Certificate monitoring TechCommunity blog https://techcommunity.microsoft.com/t5/system-center-blog/scom-management-pack-for-certificate-monitoring/ba-p/3619299

Download SCOM Certificate monitoring pack https://www.microsoft.com/en-us/download/details.aspx?id=104858

Long-standing PKI certificate pack and blog https://blog.topqore.com/new-version-pki-certificates-monitoring-pack-for-scom/

Identify certificate stores to windows folders https://superuser.com/questions/217719/what-are-the-windows-system-certificate-stores

STIG finding V-69223 https://www.stigviewer.com/stig/zos_tss/2016-06-30/finding/V-69223

Updated DNS2012R2 Addendum

DNS2012R2 addendum pack updated!

Updated DNS2012R2 Addendum overrides.  Learned a few new things with Overrides workspace views, and why Authoring pane > Management pack Objects > Overrides may not load.





When your management pack has improper overrides, expect the loading icon.  This may be caused due to overrides, whether error is with target, class/rule/monitor.

Console Overrides Loading
Console Overrides Loading



Sometimes, an Object of class error gets your hopes up (pointing at a non-existent object).

Object of Class error
Object of Class error



Example when Overrides loads properly

When Authoring Tab Overrides view loads successfully.
When Authoring Tab Overrides view loads successfully.





If Overrides view will not load, try creating a workspace view for Overrides.

Navigation Steps:

From SCOM Console

Click on My Workspace

Right Click  > New > Overrides Summary View

Create Workspace Overrides View
Create Workspace Overrides View



Select checkbox ‘with a specific override management pack’ checkbox, then the ‘specific’ link to choose management pack(s).

Select Specific Override management pack(s)
Select Specific Override management pack(s)



Choose unsealed management pack(s) with overrides

Can select all – OR pick a few to see what loads without errors

Click OK

If you get the loading screen and error, now begins the pack analysis.

OverridesViewFailsToLoad
OverridesViewFailsToLoad

Clicking on the ‘Show’ link points to a non-existent object

Microsoft.EnterpriseManagement.Common.ObjectNotFoundException: An object of class ManagementPackClass with ID 76e2559c-aaf4-b1ec-60cf-d40ab4102fbc was not found.



How did I know that?

Run get-SCOMClassInstance command from PowerShell or Operations Manager shell

Example output of ‘get-SCOMClassInstance -ID “76e2559c-aaf4-b1ec-60cf-d40ab4102fbc” ‘

Get-SCOMClassInstance output of the GUID listed in the console error.
Get-SCOMClassInstance output of the GUID listed in the console error.



Work on the Overrides of the affected XML packs, and Import.

Once corrected, the Workspace view loads successfully, finite!

Overrides Workspace view of addendum packs





Documentation

My Workspace https://learn.microsoft.com/en-us/system-center/scom/manage-web-console-my-workspace?view=sc-om-2022

Monitoring workspace https://learn.microsoft.com/en-us/system-center/scom/manage-using-monitoring-workspace?view=sc-om-2022
